NikolaTesla Fit 3Z
Design Fabrizio Crisà
สี: black
ขนาด
Products for this combination
PRF0184526
PRF0187245
NikolaTesla Fit 3Z
Design Fabrizio Crisà
Awards
Extralarge Zone
Fast Boiling
Dual Zone
Comfort Silence
Technical Specifications
Weight (Kg)
Duct-out: 17,7
Filtering: 18,5
Filtering: 18,5
Finishing
Black glass
Dimensions (cm)
60x51,5x26
Energy Class
A
Cut out
56x49 cm
Total absorption
7,2 kW
Airflow Min-Max
Duct-out: 250-850m³/h
Filtering: 210-720m³/h
Filtering: 210-720m³/h
Suction speed
5,1m/s
Noise level Min-Max aspiration
42db(A) - 61db(A)
Noise level Min-Max filter
51db(A) - 68db(A)
Controls
4S+B Slider touch control
Absorption
170 W
Controls
9P+B slider touch control
Voltage
220-240V / 380-415V 2N / 380-415V 3N
Power limitation
3,1kW - 4,5kW
Front left cooking zone
Ø 30 cm - 2,5/3,6 kW
Right front cooking zone
Ø 18 cm - 1,4/2,1 kW
Rear right cooking zone
Ø 14 cm - 0,9/1,35 kW
|
Compare models
|
|
|
|
|---|---|---|---|
| สี |
|
|
|
| Weight (Kg) |
Duct-out: 17,7 Duct-out: 19 Filtering: 18,5 Filtering: 19,5 |
Filtering: 21,4 Duct-out: 21,4 Duct-out: 24,5 Filtering: 29,5 |
17,9 |
| Finishing | Black glass |
Filtering: Black glass & stainless steel Duct-out: Black glass & stainless steel Duct-out: Matt black glass Filtering: Matt black glass |
Matt black glass |
| Dimensions (cm) |
Duct-out: 60x51,5x26 Duct-out: 72x51,5x26 Filtering: 60x51,5x26 Filtering: 72x51,5x26 |
83x51,5x21 | 72x51,5x25 |
| Energy Class | A | A++ | A |
| Cut out | 56x49 cm | 80,7x49,2 cm | 56x49 cm |
| Total absorption | 7,2 kW | 7,4 kW | 7,4 kW |
| Airflow Min-Max |
Duct-out: 250-850m³/h Filtering: 210-720m³/h |
Filtering: 170-750m³/h Duct-out: 200-900m³/h |
210-720m³/h |
| Suction speed | 5,1m/s | 5,1m/s | 5,1m/s |
| Noise level Min-Max aspiration | 42db(A) - 61db(A) | 34db(A) - 67db(A) | 43db(A) - 61db(A) |
| Noise level Min-Max filter | 51db(A) - 68db(A) | 38db(A) - 71db(A) | 44db(A) - 68db(A) |
| Controls | 4S+B Slider touch control | 9S+B Slider touch control | 4S+B Slider touch control |
| Absorption | 170 W | 175 W | 160 W |
| Controls | 9P+B slider touch control | 9P+B Touch control direct slider | 9P+B slider touch control |
| Voltage | 220-240V / 380-415V 2N / 380-415V 3N | 220-240V / 380-415V 2N / 380-415V 3N | 220-240V / 380-415V 2N / 380-415V 3N |
| Power limitation | 3,1kW - 4,5kW | 4,5kW | 3,1kW - 4,5kW |
| Front left cooking zone | Ø 30 cm - 2,5/3,6 kW | OCTA 22x18,4 cm - 2,1/3,7 kW | OCTA 21x19,1 cm - 2,1/3 kW |
| Right front cooking zone | Ø 18 cm - 1,4/2,1 kW | OCTA 22x18,4 cm - 2,1/3,7 kW | OCTA 21x19,1 cm - 1,65/1,85 kW |
| Rear right cooking zone | Ø 14 cm - 0,9/1,35 kW | OCTA 22x18,4 cm - 2,1/3,7 kW | OCTA 21x19,1 cm - 2,1/3 kW |
| Number of bridge zones | 2 | 2 | |
| Rear left cooking zone | OCTA 22x18,4 cm - 2,1/3,7 kW | OCTA 21x19,1 cm - 1,65/1,85 kW |
