Lane Sensor
Design Fabrizio Crisà
สี: สีสเตนเลส
ขนาด
Products for this combination
PRF0188199A
Lane Sensor
Design Fabrizio Crisà
Airmatic
Total Integration
Super Easy Installation
Perimeter Aspiration
Delay Switch Off
Easy to Maintain
Maintenance Alarm
Multi Connection
Dim Light
Technical Specifications
Weight (Kg)
8,2
Finishing
Stainless Steel
Dimensions (cm)
60
Energy Class
B
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
57cm
Duct Transition
150mm
Lighting
Strip Led 1x7 W - 3500 K - 421 LUX
Absorption
257W
Airflow Min-Max
300-800m³/h
Noise level Min-Max
49db(A) - 65db(A)
Controls
3S+B Electronic push button
ดาวน์โหลด
|
Compare models
|
|
|
|
|---|---|---|---|
| สี |
|
|
|
| Weight (Kg) |
8,2 9,6 |
GFA: 5,25 ST: 5,6 ST: 6,7 LX: 5,6 LX: 6,95 GFA: 6,8 LX: 6 |
12,4 10,3 13 |
| Finishing |
Stainless Steel Black Matte |
GFA: White ST: Stainless Steel LX: Stainless Steel GFA: Black LX: White LX: Black |
Stainless Steel + Glass |
| Dimensions (cm) |
60 80 |
GFA: 60 ST: 60 ST: 90 LX: 60 LX: 90 GFA: 90 LX: 70 |
90 60 120 |
| Energy Class | B | D | B |
| Minimum distance from wall unit induction/radiant hob | 50cm | 50cm | 50cm |
| Minimum distance from wall unit gas hob | 57cm | 65cm | 50cm |
| Duct Transition | 150mm | 120mm | 150mm |
| Lighting | Strip Led 1x7 W - 3500 K - 421 LUX |
GFA: Led 2x3 W - 2700 K - 121 LUX ST: Led 1x3 W - 2700 K - 84 LUX LX: Led 2x3 W - 2700 K - 97 LUX |
Led 2x2,5 W - 3500 K - 145 LUX Led 2x2,5 W - 3500 K - 381 LUX |
| Absorption | 257W |
GFA: 101W ST: 98W LX: 166W |
255W |
| Airflow Min-Max | 300-800m³/h |
GFA: 150-350m³/h ST: 150-350m³/h LX: 250-450m³/h |
300-800m³/h |
| Noise level Min-Max | 49db(A) - 65db(A) |
GFA: 50db(A) - 64db(A) ST: 50db(A) - 64db(A) LX: 52db(A) - 73db(A) |
46db(A) - 67db(A) 48db(A) - 67db(A) |
| Controls | 3S+B Electronic push button | 3S Mechanical slider | 3S Mechanical push button |
