Krea
Elica Design Center
Color: Stainless steel
Width
Products for this combination
55311075B
55311129A
Krea
Elica Design Center
Technical Specifications
Weight (Kg)
ST: 6,7
LX: 6,95
LX: 6,95
Finishing
Stainless Steel
Dimensions (cm)
90
Energy Class
D
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
65cm
Duct Transition
120mm
Lighting
ST: Led 1x3 W - 2700 K - 84 LUX
LX: Led 2x3 W - 2700 K - 97 LUX
LX: Led 2x3 W - 2700 K - 97 LUX
Absorption
ST: 98W
LX: 166W
LX: 166W
Airflow Min-Max
ST: 125m³/h - 265m³/h
LX: 135m³/h - 336m³/h
LX: 135m³/h - 336m³/h
Noise level Min-Max
ST: 50db(A) - 64db(A)
LX: 52db(A) - 73db(A)
LX: 52db(A) - 73db(A)
Controls
3S Mechanical slider
Compatible accessories
|
Model
Find the right spare part by checking the specifications with the PRF code
|
 KREA ST IX F/90
55311075B
|
 KREA LX IX F/90
55311129A
|
| Venting Type | ST | LX |
|---|---|---|
| Weight (Kg) | 6,7 | 6,95 |
| Lighting | Led 1x3 W - 2700 K - 84 LUX | Led 2x3 W - 2700 K - 97 LUX |
| Absorption | 98W | 166W |
| Airflow Min-Max | 125m³/h - 265m³/h | 135m³/h - 336m³/h |
| Noise level Min-Max | 50db(A) - 64db(A) | 52db(A) - 73db(A) |
| View accessories | View accessories |
