Krea
Elica Design Center
Color: black
Size
Products for this combination
PRF0104634B
Krea
Elica Design Center
Technical Specifications
Weight (Kg)
5,25
Finishing
Black
Dimensions (cm)
60
Energy Class
D
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
65cm
Duct Transition
120mm
Lighting
Led 2x3 W - 2700 K - 121 LUX
Absorption
101W
Airflow Min-Max
125m³/h - 265m³/h
Noise level Min-Max
50db(A) - 64db(A)
Controls
3S Mechanical slider
Downloads
Download the technical sheet Krea
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
LX: 6,95 GFA: 5,25 GFA: 6,8 5,6 |
12,1 9,6 14,5 |
8,25 9,6 8,9 10,5 8,7 10,1 |
| Finishing |
LX: Stainless Steel GFA: Black Stainless Steel |
Stainless Steel |
Stainless Steel Stainless Steel + White Glass Black Matte |
| Dimensions (cm) |
LX: 90 GFA: 60 GFA: 90 60 |
90 60 120 |
60 80 |
| Energy Class | D | B | A |
| Minimum distance from wall unit induction/radiant hob | 50cm | 50cm | 50cm |
| Minimum distance from wall unit gas hob | 65cm | 50cm | 65cm |
| Duct Transition | 120mm | 150mm | 150mm |
| Lighting |
LX: Led 2x3 W - 2700 K - 97 LUX GFA: Led 2x3 W - 2700 K - 121 LUX Led 2x3 W - 2700 K - 97 LUX |
Led 2x2,1 W - 3500 K - 181 LUX Led 3x2,1 W - 3500 K - 211 LUX |
Strip Led 1x7 W - 3500 K - 421 LUX |
| Absorption |
LX: 166W GFA: 101W 166W |
255W 257.5W |
277W |
| Airflow Min-Max |
LX: 135m³/h - 336m³/h GFA: 125m³/h - 265m³/h 135m³/h - 336m³/h |
270m³/h - 700m³/h | 300m³/h - 690m³/h |
| Noise level Min-Max |
LX: 52db(A) - 73db(A) GFA: 50db(A) - 64db(A) 52db(A) - 73db(A) |
52db(A) - 67db(A) | 51db(A) - 67db(A) |
| Controls | 3S Mechanical slider | 3S+B Electronic push button | 3S+B Electronic push button |
