CT35 Pro
Elica Design Center
Color: Stainless steel
Size
Products for this combination
PRF0183203
CT35 Pro
Elica Design Center
Plus
Technical Specifications
Weight (Kg)
11
Finishing
Stainless Steel
Dimensions (cm)
60
Energy Class
A
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
65cm
Duct Transition
150mm
Lighting
Strip Led 2x3 W - 4200 K - 121 LUX
Absorption
281W
Airflow Min-Max
225m³/h - 650m³/h
Noise level Min-Max
51db(A) - 73db(A)
Controls
3S+B Electronic push button
Downloads
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
60: 11 90: 15 120: 18,5 |
GFA: 5,25 ST: 5,6 ST: 6,7 LX: 5,6 LX: 6,95 GFA: 6,8 |
5,5 4,8 |
| Finishing | Stainless Steel |
GFA: White ST: Stainless Steel LX: Stainless Steel GFA: Black |
Stainless Steel Black |
| Dimensions (cm) |
60: 60 90: 90 120: 120 |
GFA: 60 ST: 60 ST: 90 LX: 60 LX: 90 GFA: 90 |
80 60 |
| Energy Class | A | D | B |
| Minimum distance from wall unit induction/radiant hob | 50cm | 50cm | 50cm |
| Minimum distance from wall unit gas hob | 65cm | 65cm | 65cm |
| Duct Transition | 150mm | 120mm | 120mm |
| Lighting |
60: Strip Led 2x3 W - 4200 K - 121 LUX 90: Strip Led 2x3 W - 4200 K - 97 LUX 120: Strip Led 2x3 W - 4200 K - 73 LUX |
GFA: Led 2x3 W - 2700 K - 121 LUX ST: Led 1x3 W - 2700 K - 84 LUX LX: Led 2x3 W - 2700 K - 97 LUX |
Led 2x3 W - 2700 K - 73 LUX |
| Absorption | 281W |
GFA: 101W ST: 98W LX: 166W |
121W |
| Airflow Min-Max |
60: 225m³/h - 650m³/h 90: 255m³/h - 750m³/h 120: 265m³/h - 780m³/h |
GFA: 125m³/h - 265m³/h ST: 125m³/h - 265m³/h LX: 135m³/h - 336m³/h |
236m³/h - 428m³/h |
| Noise level Min-Max |
60: 51db(A) - 73db(A) 90: 50db(A) - 69db(A) 120: 52db(A) - 69db(A) |
GFA: 50db(A) - 64db(A) ST: 50db(A) - 64db(A) LX: 52db(A) - 73db(A) |
57db(A) - 68db(A) |
| Controls | 3S+B Electronic push button | 3S Mechanical slider | 3S Mechanical rotative |
