Boxin No Drip 2.0
Color: Stainless steel
Size
Products for this combination
PRF0211341
PRF0205572
Boxin No Drip 2.0
Technical Specifications
Weight (Kg)
10,7
10,4
10,4
Finishing
Stainless Steel
Stainless Steel
Stainless Steel
Dimensions (cm)
60
Energy Class
A
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
62cm
Duct Transition
150mm
Lighting
Strip Led 1x7 W - 3500 K - 421 LUX
Absorption
286W
Airflow Min-Max
140m³/h - 700m³/h
140m³/h - 680m³/h
140m³/h - 680m³/h
Noise level Min-Max
36db(A) - 66db(A)
Controls
3S+B Electronic push button
Original accessories
|
Model
Find the right spare part by checking the specifications with the PRF code
|
BOXIN NO DRIP 2.0 VL IX/A/60
PRF0211341
|
 BOXIN NO DRIP 2.0 IX/A/60
PRF0205572
|
| Venting Type | PRF0211341 | PRF0205572 |
|---|---|---|
| Weight (Kg) | 10,7 | 10,4 |
| Finishing | Stainless Steel | Stainless Steel |
| Airflow Min-Max | 140m³/h - 700m³/h | 140m³/h - 680m³/h |
| View accessories | View accessories |
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
10,7 13,65 16,3 Duct-out: 8,75 Duct-out: 11,2 10,4 12,55 Duct-out: 14,9 14,8 |
STD: 7,8 STD: 9,5 STD: 12,1 LX: 8,7 LX: 10,25 LX: 12,6 LX: 8,9 LX: 10,5 STD: 12,6 LX: 9,5 |
6,8 8,4 |
| Finishing |
Stainless Steel Duct-out: Nero opaco |
STD: Stainless Steel LX: Stainless Steel |
Stainless Steel + Grey |
| Dimensions (cm) |
60 90 120 Duct-out: 60 Duct-out: 90 Duct-out: 120 |
STD: 60 STD: 90 STD: 120 LX: 60 LX: 90 LX: 120 LX: 75 |
60 90 |
| Energy Class | A |
STD: D LX: A STD: A |
D |
| Minimum distance from wall unit induction/radiant hob | 50cm |
STD: 45cm LX: 50cm STD: 50cm |
50cm |
| Minimum distance from wall unit gas hob | 62cm | 50cm | 65cm |
| Duct Transition | 150mm | 150mm | 120mm |
| Lighting |
Strip Led 1x7 W - 3500 K - 421 LUX Strip Led 1x7 W - 3500 K - 365 LUX Duct-out: Strip Led 1x7 W - 3500 K - 421 LUX Duct-out: Strip Led 1x7 W - 3500 K - 365 LUX |
Led 2x2,5 W - 3500 K - 381 LUX | Led 2x3 W - 2700 K - 73 LUX |
| Absorption |
286W 307W 325W Duct-out: 286W Duct-out: 307W Duct-out: 325W |
STD: 95W LX: 255W STD: 255W |
121W |
| Airflow Min-Max |
140m³/h - 700m³/h Duct-out: 140m³/h - 700m³/h 140m³/h - 680m³/h |
STD: 140m³/h - 370m³/h LX: 255m³/h - 620m³/h STD: 255m³/h - 620m³/h LX: 245m³/h - 620m³/h |
125m³/h - 304m³/h |
| Noise level Min-Max | 36db(A) - 66db(A) |
STD: 48db(A) - 67db(A) LX: 50db(A) - 70db(A) STD: 50db(A) - 70db(A) LX: 48db(A) - 69db(A) |
46db(A) - 62db(A) |
| Controls | 3S+B Electronic push button | 3S Mechanical rotative | 3S Mechanical push button |
