Elite 14
Elica Design Center
Color: grey
Size
Products for this combination
PRF0037989B
PRF0098874B
PRF0116536B
Elite 14
Elica Design Center
Technical Specifications
Weight (Kg)
6,8
5,5
6
5,5
6
Finishing
Stainless Steel + Grey
Grey + Black Glass
Grey + White Glass
Grey + Black Glass
Grey + White Glass
Dimensions (cm)
60
Energy Class
D
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
65cm
Duct Transition
120mm
Lighting
Led 2x3 W - 2700 K - 73 LUX
Absorption
121W
MOTOR 650
650
Airflow Min-Max
125m³/h - 304m³/h
Noise level Min-Max
46db(A) - 62db(A)
Controls
3S Mechanical push button
Original accessories
|
Model
Find the right spare part by checking the specifications with the PRF code
|
ELITE 14 LUX GRIX/A/60
PRF0037989B
|
 ELITE 14 LUX GRVT/A/60
PRF0098874B
|
 ELITE 14 LUX GRVTWH/A/60
PRF0116536B
|
| Venting Type | PRF0037989B | PRF0098874B | PRF0116536B |
|---|---|---|---|
| Weight (Kg) | 6,8 | 5,5 | 6 |
| Finishing | Stainless Steel + Grey | Grey + Black Glass | Grey + White Glass |
| View accessories | View accessories | View accessories |
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
5 6,15 6,8 6,2 8,4 9 5,5 8,6 6 |
7,2 8,8 |
8,7 13,7 11,2 10 8,8 11,8 14,1 |
| Finishing |
Stainless Steel + Grey White Black Grey + Black Glass Grey + White Glass Stainless Steel Tutto Nero + Vetro Nero |
Grey |
Stainless Steel Nero opaco Nero opaco + Vetro Nero |
| Dimensions (cm) |
50 60 90 61 |
60 90 |
60 120 90 75 |
| Energy Class |
D C |
B | A |
| Minimum distance from wall unit induction/radiant hob |
50cm |
50cm | 43cm |
| Minimum distance from wall unit gas hob |
65cm |
65cm | 57cm |
| Duct Transition |
120mm 121mm |
120mm | 150mm |
| Lighting |
Led 2x3 W - 2700 K - 73 LUX Led 2x3 W - 2700 K - 78 LUX |
Led 2x2,5 W - 3500 K - 141 LUX |
Strip Led 1x7 W - 3500 K - 421 LUX Strip Led 1x7 W - 3500 K - 365 LUX |
| Absorption | 121W | 120W | 177W |
| MOTOR 650 |
650 |
||
| MOTOR 800 | 800 | ||
| Airflow Min-Max |
125m³/h - 304m³/h 272m³/h - 400m³/h |
255m³/h - 425m³/h | 180m³/h - 640m³/h |
| Noise level Min-Max |
46db(A) - 62db(A) 60db(A) - 70db(A) |
57db(A) - 69db(A) | 45db(A) - 57db(A) |
| Controls | 3S Mechanical push button | 3S Mechanical slider | 3S+B Electronic push button |
