Boxin Lux
Elica Design Center
Color: black
Width
Products for this combination
PRF0172168
Boxin Lux
Elica Design Center
Cabinet Protection
Protected wall units, the perfect kitchen.
A special design that ensures total protection of your wall units from cooking vapours. The side protections together with the ergonomic front visor will prevent any potential wear-out.
Total Integration
Total & Perfect Look.
Our household appliances discreetly adapt to the design and features of your kitchen. The variety of solutions and finishing touches blend in perfectly whatever your taste in style may be.
Easy to Maintain
The perfect product with easy maintenance.
Proper maintenance and maximum hygiene, ensure a longer lifespan of the appliance. Our models have been conceived to make the replacement of grease filters and odour filters easier: all are removable, washable and replaceable.
Technical Specifications
Weight (Kg)
12,6
Finishing
Stainless Steel
Dimensions (cm)
120
Energy Class
A
Minimum distance from wall unit induction/radiant hob
50cm
Minimum distance from wall unit gas hob
50cm
Duct Transition
150mm
Lighting
Led 2x2,5 W - 3500 K - 381 LUX
Absorption
255W
Airflow Min-Max
255m³/h - 620m³/h
Noise level Min-Max
50db(A) - 70db(A)
Controls
3S Mechanical rotative
Compatible accessories
Downloads
Download the technical sheet Boxin Lux
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
LX: 8,7 LX: 10,25 LX: 12,6 LX: 8,9 LX: 10,5 STD: 12,6 |
10,35 13,25 17,2 |
9,6 11,5 14,3 |
| Finishing |
LX: Stainless Steel STD: Stainless Steel |
Stainless Steel + White Glass | Stainless Steel |
| Dimensions (cm) |
LX: 60 LX: 90 LX: 120 STD: 120 |
60 90 120 |
60 90 120 |
| Energy Class | A | B | A+ |
| Minimum distance from wall unit induction/radiant hob | 50cm | 50cm | 43cm |
| Minimum distance from wall unit gas hob | 50cm | 50cm | 57cm |
| Duct Transition | 150mm | 150mm | 150mm |
| Lighting | Led 2x2,5 W - 3500 K - 381 LUX | Led 2x2,5 W - 3500 K - 381 LUX |
Strip Led 1x7 W - 3000 K - 3500 K - 4000 K - 421 LUX Strip Led 1x7 W - 3000 K - 3500 K - 4000 K - 365 LUX Strip Led 1x7 W - 3000 K - 3500 K - 4000 K - 309 LUX |
| Absorption | 255W | 255W | 177W |
| Airflow Min-Max | 255m³/h - 620m³/h | 230m³/h - 610m³/h | 205m³/h - 660m³/h |
| Noise level Min-Max | 50db(A) - 70db(A) | 49db(A) - 70db(A) | 45db(A) - 58db(A) |
| Controls | 3S Mechanical rotative | 3S Mechanical rotative | 3S+B Electronic push button |
