Fold S
Elica Design Center
Color: Stainless steel
Width
Products for this combination
PRF0189419
Fold S
Elica Design Center
Plus
Technical Specifications
Weight (Kg)
7.6
Finishing
Stainless Steel
Dimensions (cm)
80
Energy Class
B
Minimum distance from wall unit induction/radiant hob
45cm
Minimum distance from wall unit gas hob
65cm
Duct Transition
150mm
Lighting
Strip Led 1x7 W - 3500 K - 477 LUX
Absorption
257W
Airflow Min-Max
300m³/h - 710m³/h
Noise level Min-Max
53db(A) - 66db(A)
Controls
3S+B Electronic push button
Downloads
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
6.4 7.6 |
8.25 9.6 8.9 10.5 8.7 10.1 |
LX: 8.7 LX: 10.25 LX: 12.6 LX: 8.9 LX: 10.5 STD: 12.6 |
| Finishing | Stainless Steel |
Stainless Steel Stainless Steel + White Glass Black Matte |
LX: Stainless Steel STD: Stainless Steel |
| Dimensions (cm) |
60 80 |
60 80 |
LX: 60 LX: 90 LX: 120 STD: 120 |
| Energy Class | B | A | A |
| Minimum distance from wall unit induction/radiant hob | 45cm | 50cm | 50cm |
| Minimum distance from wall unit gas hob | 65cm | 65cm | 50cm |
| Duct Transition | 150mm | 150mm | 150mm |
| Lighting | Strip Led 1x7 W - 3500 K - 477 LUX | Strip Led 1x7 W - 3500 K - 421 LUX | Led 2x2,5 W - 3500 K - 381 LUX |
| Absorption | 257W | 277W | 255W |
| Airflow Min-Max | 300m³/h - 710m³/h | 300m³/h - 690m³/h | 255m³/h - 620m³/h |
| Noise level Min-Max | 53db(A) - 66db(A) | 51db(A) - 67db(A) | 50db(A) - 70db(A) |
| Controls | 3S+B Electronic push button | 3S+B Electronic push button | 3S Mechanical rotative |
