NikolaTesla Fit Xl
Design Fabrizio Crisà
The linear design and installation flexibility of NikolaTesla FIT also in the 80 cm version now.
Color: black
Width
Products for this combination
PRF0179476
PRF0210734
NikolaTesla Fit Xl
Design Fabrizio Crisà
The linear design and installation flexibility of NikolaTesla FIT also in the 80 cm version now.
Excellence, even in large spaces.
The black glass is the paradigm of this appliance, designed to fit seamlessly into any kitchen with unparalleled versatility. The extractor system is invisible, silent, and automatic. It powers on with a simple tap of the finger. The induction hob, featuring a double bridge zone to unlock a multitude of cooking possibilities, is easy to use and intuitive. With the extraction unit closed, the appliance presents clean, visually striking lines. The slider control makes it extremely easy to use the features on the hob; the highly efficient extraction system captures odours and vapours. The long-life filters are easy to remove and there is a special valve to drain accidental spills, ensuring total hygiene.The product is also available in the exclusive Raw version, a finish that further enhances its contemporary and distinctive character. The anti-fingerprint surface of the NikolaTesla Fit XL Raw is more resistant to scratches, daily use and the passage of time, making cleaning and maintenance easier.
Plus
Technical Specifications
Weight (Kg)
Duct-out: 18.8
Duct-out: 18.4
Duct-out: 18.4
Finishing
Black glass
Dimensions (cm)
Duct-out: 83x51,5x25
Duct-out: 83x51,5x19,4
Duct-out: 83x51,5x19,4
Energy Class
Duct-out: A
Duct-out: A+
Duct-out: A+
Cut out
75x49 cm
Total absorption
Duct-out: 7,4 kW
Duct-out: 7,5 kW
Duct-out: 7,5 kW
Airflow min duct-out
Duct-out: 220m³/h
Duct-out: 155m³/h
Duct-out: 155m³/h
Airflow max duct-out
500m³/h
Airflow boost duct-out
620m³/h
Airflow min filtering
Duct-out: 135m³/h
Duct-out: 155m³/h
Duct-out: 155m³/h
Airflow max filtering
Duct-out: 420m³/h
Duct-out: 465m³/h
Duct-out: 465m³/h
Airflow Filtering
Duct-out: 520m³/h
Duct-out: 580m³/h
Duct-out: 580m³/h
Suction speed
Duct-out: 5.1m/s
Noise level Min-Max aspiration
Duct-out: 43db(A) - 61db(A)
Duct-out: 42db(A) - 69db(A)
Duct-out: 42db(A) - 69db(A)
Noise level Min-Max filter
Duct-out: 44db(A) - 68db(A)
Duct-out: 51db(A) - 75db(A)
Duct-out: 51db(A) - 75db(A)
Controls
4S+B Slider touch control
Absorption
Duct-out: 160 W
Duct-out: 350 W
Duct-out: 350 W
Controls
9P+B slider touch control
Voltage
220-240V / 380-415V 2N / 380-415V 3N
Power limitation
Duct-out: 3,1kW - 4,5kW
Number of bridge zones
2
Front left cooking zone
OCTA 21x19,1 cm - 1,65/1,85 kW
Right front cooking zone
OCTA 21x19,1 cm - 1,65/1,85 kW
Rear left cooking zone
OCTA 21x19,1 cm - 2,1/3 kW
Rear right cooking zone
OCTA 21x19,1 cm - 2,1/3 kW
Compatible accessories
|
Model
Find the right spare part by checking the specifications with the PRF code
|
 NIKOLATESLA FIT XL BL/A/83
PRF0179476
|
NIKOLATESLA FIT XL SL BL/A/83
PRF0210734
|
| Venting Type | Duct-out | Duct-out |
|---|---|---|
| Weight (Kg) | ||
| Dimensions (cm) | ||
| Energy Class | ||
| Total absorption | ||
| Airflow min duct-out | ||
| Airflow min filtering | ||
| Airflow max filtering | ||
| Airflow Filtering | ||
| Suction speed | ||
| Noise level Min-Max aspiration | ||
| Noise level Min-Max filter | ||
| Absorption | ||
| Power limitation | ||
| Power limitation | ||
| View accessories | View accessories |
|
Compare models
|
|
|
|
|---|---|---|---|
| Color |
|
|
|
| Weight (Kg) |
Duct-out: 18.8 Duct-out: 18.4 |
19.25 | 22.4 |
| Finishing |
Duct-out: Black glass Duct-out: Matt black glass |
Duct-out: Black glass Duct-out: Matt black glass |
Duct-out: White glass "ice grey" + cast iron Duct-out: Black glass + cast iron |
| Dimensions (cm) |
Duct-out: 83x51,5x25 Duct-out: 83x51,5x19,4 |
83x51,5x21 | 83x51,5x21 |
| Energy Class |
Duct-out: A Duct-out: A+ |
A++ | A+ |
| Cut out | 75x49 cm | 80,7x49,2 cm | 80,7x49,2 cm |
| Total absorption |
Duct-out: 7,4 kW Duct-out: 7,5 kW |
7,4 kW | 7,4 kW |
| Airflow min duct-out |
Duct-out: 220m³/h Duct-out: 155m³/h |
135m³/h | 160m³/h |
| Airflow max duct-out | 500m³/h | 525m³/h | 480m³/h |
| Airflow boost duct-out | 620m³/h | 620m³/h | 600m³/h |
| Airflow min filtering |
Duct-out: 135m³/h Duct-out: 155m³/h |
125m³/h | 145m³/h |
| Airflow max filtering |
Duct-out: 420m³/h Duct-out: 465m³/h |
495m³/h | 435m³/h |
| Airflow Filtering |
Duct-out: 520m³/h Duct-out: 580m³/h |
570m³/h | 550m³/h |
| Suction speed |
Duct-out: 5.1m/s |
5.1m/s | 5.1m/s |
| Noise level Min-Max aspiration |
Duct-out: 43db(A) - 61db(A) Duct-out: 42db(A) - 69db(A) |
35db(A) - 67db(A) | 38db(A) - 64db(A) |
| Noise level Min-Max filter |
Duct-out: 44db(A) - 68db(A) Duct-out: 51db(A) - 75db(A) |
38db(A) - 71db(A) | 41db(A) - 67db(A) |
| Controls | 4S+B Slider touch control | 9S+B Slider touch control | 4S+B Slider touch control |
| Absorption |
Duct-out: 160 W Duct-out: 350 W |
175 W | 160 W |
| Controls | 9P+B slider touch control | 9P+B slider touch control | 9P+B slider touch control |
| Voltage | 220-240V / 380-415V 2N / 380-415V 3N | 220-240V / 380-415V 2N / 380-415V 3N | 220-240V / 380-415V 2N / 380-415V 3N |
| Power limitation |
Duct-out: 3,1kW - 4,5kW |
3,1kW - 4,5kW | 3,1kW - 4,5kW |
| Number of bridge zones | 2 | 1 (SX) | 2 |
| Front left cooking zone | OCTA 21x19,1 cm - 1,65/1,85 kW | OCTA 21x19,1 cm - 1,65/1,85 kW | OCTA 21x19,1 cm - 1,65/1,85 kW |
| Right front cooking zone | OCTA 21x19,1 cm - 1,65/1,85 kW | Ø 16 cm - 1,2/1,4 kW | OCTA 21x19,1 cm - 1,65/1,85 kW |
| Rear left cooking zone | OCTA 21x19,1 cm - 2,1/3 kW | OCTA 21x19,1 cm - 2,1/3 kW | OCTA 21x19,1 cm - 2,1/3 kW |
| Rear right cooking zone | OCTA 21x19,1 cm - 2,1/3 kW | Ø 20 cm - 2,3/3 kW | OCTA 21x19,1 cm - 2,1/3 kW |
